New Commodore 128 Community Edition PCB by Jorgen Olsson

New Commodore 128 CE (Community Edition) PCB was reverse engineered by Jorgen Olsson and published on github and is work in progress.

Current status of preoject is Jorgen is working on the PCB in DipTrace, using the CorelDRAW images as guide to lay traces, components, vias, board outline and cutouts. As soon he finish net lists and all traces laid in both signal layers he will add the project files in the repository.

In the CorelDRAW images, there may be some mistakes ie missing traces, so check github for new commits and new images.

source:Commodore 128 Community Edition PCB on github
